試驗室XFG型掛槽浮選機技術參數 Technical Parame

該浮選機用于地質、冶金、建材、化工、煤炭、礦山選廠及院?？蒲袉挝辉囼炇覕嚢琛⒎蛛x、擦洗、精選礦樣等。本產品由原地礦部唯一指定企業生產，執行行業標準。

The flotation machines are employed for agitation , separation, scrubbing and cleaning of samples in labs of geological, metallurgical, building material, chemical, coal, beneficiation plant of mine , institutions of higher learning and research institutions. The product is produced by the only manufacturer designated by the former. Ministry of Geology and Mineral Resources, in compliance with the Industrial standards.

XFG型掛槽浮選機XFG Model Hanging Cell Flotation Machine

XFG型掛槽浮選機用于攪拌、擦洗、分離和精選少量礦樣等。該機具有浮選速度快和選別指標好等特點。

XFG Model Hanging Cell Flotation Machine is used for agitation separation, scrubbing and cleaning of minor samples with rapid speed of flotation and desirable separation indexes and other features.

型號規格 Model	容量 Capa.	選槽容積 Volume	葉輪直徑 Impeller diameter	葉輪轉速 Impeller speed	給礦粒度 Feed size	功率 Motor power	質量 Weight
型號規格 Model	g	ML	mm	r/min	mm	w	kg
XFG 5 -35克	5、15 25、35	20、60 100、140	Φ20、Φ26、Φ30	1000-1850	≤0.2	90	15
XFG 50 -100克	50、100	200 400	Φ36、Φ48	1000-1850	≤0.2	90	16
XFG 250 -500克	250、500	1000 2000	Φ60、Φ64	1500、2000	≤0.2	250	25
XFG 1000克	1000	4000	Φ80	900、1500	≤0.2	250	27
